The AC10 drive is a simple, small, and reliable variable speed drive and offers a low cost, compact solution for simple AC induction or PMAC motor control in applications up to 250 HP
AC Variable Frequency Drive 10G-44-0230-BF (10G/44/0230/BF)
The AC10 drive is a simple, small, and reliable variable speed drive and offers a low cost, compact solution for simple AC induction or PMAC motor control in applications up to 250 HP
Specifications:
Performance Characteristics
|
BRAND |
Parker |
| PRODUCT TYPE | AC Drive |
| DRIVE FORMAT | Single Axis Technology |
| SERIES | AC10 |
| INPUT SUPPLY VOLTAGE |
1*230VAC 3*230VAC 3*380-480VAC |
| CONTINUOUS OUTPUT CURRENT RATING | |
| OUTPUT RATING (HP) | 0.25 - 250 HP (IP20) / 0.5 - 20 HP (IP66) |
| SUPPORTED MOTOR TYPES | Induction |
| SUPPORTED FEEDBACK DEVICE | |
| MODES OF CONTROL |
V/Hz Sensorless Vector |
| COMMUNICATION INTERFACE |
RS232 / RS485 Modbu |
| OPERATING TEMPERATURE (C) | 0-40C (derate up to 50C max) |
| OPERATING TEMPERATURE (F) | 32-104F (derate up to 122F max) |
| OPERATING ALTITUDE | Up to 1000m ASL (derate > 1000m) |
| OVERLOAD RATINGS | 150% for 60s |
| CERTIFICATES |
CE (EMC & LVD) Overvoltage Category III |
