Home Products Parker 650, 690 AC DRIVE 650G series AC DRIVE 4kW 230V 1ph to 3ph

Products

4kW 230V 1ph to 3ph
4kW 230V 1ph to 3ph 4kW 230V 1ph to 3ph 4kW 230V 1ph to 3ph 4kW 230V 1ph to 3ph

4kW 230V 1ph to 3ph

Product ID : AC650G SERIES
Product Attributes :

The AC650G is an entry level AC drive designed to provide cost-effective control of AC induction motors used in many everyday industrial applications, up to 10HP, and is ideally suited to energy saving in pump and fan applications.

Product Description

AC VARIABLE FREQUENCY DRIVES, HP RATED - AC650G SERIES



The DC512C series analog 2-quadrant DC drives offer 4-32A output ratings and isolated control circuits, making it suitable for single or multi-axis low power applications which require speed or torque control of permanent magnet or wound field DC motors




Specifications:

Performance Characteristics


BRAND Parker
PRODUCT TYPEAC Drive
DRIVE FORMAT Single Axis Technolog

OUTPUT RATING (HP)


0.3 - 10HP
INPUT VOLTAGE 1*230VAC | 3*230VAC | 3*380-460VAC
COMMUNICATION INTERFACE RS232 / RS485 | Profibus
OPERATING CONTROL MODES V/Hz | Sensorless Vector
CERTIFICATES  CE(EMC & LVD) | UL Listed | cUL Listed
OPERATING TEMPERATURE (C) 0-40C (derate up to 50C max)
OPERATING TEMPERATURE (F) 32-104F (derate up to 122F max)
OPERATING ALTITUDE Up to 1000m ASL (derate > 1000m)
OVERLOAD RATINGS Heavy Duty Rating (Constant Torque) : 150% for 60s | Normal Duty Rating (Variable Torque - pumps and fans) : 110% for 60s
