The AC650G is an entry level AC drive designed to provide cost-effective control of AC induction motors used in many everyday industrial applications, up to 10HP, and is ideally suited to energy saving in pump and fan applications.
V/F Control Transducer AC Variable Frequency Drives HP Rated - AC650G Series
The DC512C series analog 2-quadrant DC drives offer 4-32A output ratings and isolated control circuits, making it suitable for single or multi-axis low power applications which require speed or torque control of permanent magnet or wound field DC motors
Specifications:
Performance Characteristics
| BRAND | Parker |
| PRODUCT TYPE | AC Drive |
| DRIVE FORMAT | Single Axis Technolog |
|
OUTPUT RATING (HP)
|
0.3 - 10HP |
| INPUT VOLTAGE | 1*230VAC | 3*230VAC | 3*380-460VAC |
| COMMUNICATION INTERFACE | RS232 / RS485 | Profibus |
| OPERATING CONTROL MODES | V/Hz | Sensorless Vector |
| CERTIFICATES | CE(EMC & LVD) | UL Listed | cUL Listed |
| OPERATING TEMPERATURE (C) | 0-40C (derate up to 50C max) |
| OPERATING TEMPERATURE (F) | 32-104F (derate up to 122F max) |
| OPERATING ALTITUDE | Up to 1000m ASL (derate > 1000m) |
| OVERLOAD RATINGS | Heavy Duty Rating (Constant Torque) : 150% for 60s | Normal Duty Rating (Variable Torque - pumps and fans) : 110% for 60s |
